HMEs

HME, Trach, Aero-T * TV Range (ml): >50 * Moisture Output (mg/L): 26/Vt 500 * Weight (grams): 5.0 * Resistance (cmH2O): 0.48, 30 LPM * Dead Space: 10.5

The Hydro-Trach™ T is a heat and moisture exchange device for use on tracheotomized patients. It is designed for use with spontaneously breathing patients to reduce loss of heat and moisture during respiration. Features: * Clear housing for easy visual inspection * Clipped suction port for easier suctioning without device removal * Anti-occlusion mechanism allows the HME element to partially dislodge * Small and lightweight * Available with or without a swivel tube connector * Available with or without oxygen tubing Specifications: * Moisture Loss: 13.2mg H2O/L * Calculated Moisture Return: 26mg H2O/L * Resistance at 30L/min: 0.3 cm H2O * Resistance at 60L/min: 0.6 cm H2O * Compressible volume: 17 ml * Weight: 6 to 8g * Connectors: 15ID * Minimum tidal volume: >60ml All quoted performance figures are mean values.

A novel approach to ventilation management, the Gibeck® Humid-Flo® HME promotes best practices for VAP risk reduction. Designed to remain in-line for 72 hours even when aerosol treatments are given. Two operating modes, HME and AEROSOL, are enabled by rotating the blue collar. Select HME, and the Gibeck Humid-Flo will operate as a traditional Heat & Moisture Exchanger. Select AEROSOL, and the HME element is bypassed and a center passageway is exposed, allowing the delivery of aerosolized medication.Benefits: * Advances patient safety by reducing the frequency of ventilator circuit breaks. * Maximizes clinical outcomes by eliminating the need to interrupt ventilation, allowing PEEP to be maintained. * Reduces potential of caregiver exposure to depressurizing circuits by reducing the frequency of ventilator circuit breaks.

A dedicated range of heat and moisture exchangers designed to replicate the functions of the body's upper airway by conserving expired heat and moisture and returning these to the patient during inhalation. All quoted performance figures are mean values. Hydro-Therm™ HME Features: * Moisture loss: 7.8 mg H2O/l * Calculated moisture return: 30.8 mg H2O/l * Resistance at 30L/min: 0.5 cm H2O * Resistance at 60L/min: 1.6 cm H2O * Compressible volume: 20 ml * Weight: 11.8 g * Connectors: 15M-22M/15F * Minimum tidal volume: >60ml Hydro-Therm™ Micro HME Features: * Moisture loss: 9.2 mg H2O/L * Calculated moisture return: 29.5 mg H2O/l * Resistance at 5L/min: 0.3 cm H2O * Resistance at 10L/min: 0.8 cm H2O * Dead space: 2.2 ml * Weight: 2.8g * Connectors: 15ID/15OD * Minimum tidal volume: >10ml

Heat and Moisture Exchangers exhibit low resistance to flow and high moisture output in ventilated or spontaneously breathing patients.Features: * Efficient heat and moisture recovery * ISO standard tapered ends to assure a consistent leak-free seal

Thermovent® T2 Heat and Moisture Exchanger features include: * Simple opening port allows quick and easy access for suction catheter to aid in removal of secretions * Clear housing gives an aesthetic appearance and allows visualization of contamination * Integrated oxygen port can provide up to 60% oxygen concentrations to patient via simplest of connections * T paper media provides high level performance heat and moisture exchange to patient * Smooth, rounded edges aids patient comfort * 24-Hour Max Use * Sterile * Single Use

Supplemental Oxygen Delivery Adapter HME, for Thermovent T

Heat moisture exchanger is disposable.

The Ventec External Bacterial Filter captures 99.99% of bacteria and viruses. This product is a low resistance external bacteral filter. Smaller in size, the filter makes transport easier and reduces the rick of disconnects. Features: * Latex-free * Sterile * Disposable * Specific to the VOCSN Ventilator

Universal IPPB features: * For use with all I.P.P.B. machines * Sensitive exhalation valve with clear cap for accurate view of value function * Expiratory flow diverter directs gas away from therapist and patient * Complete with high - output nebulizer with 20mL jar capacity, mouthpiece, 6in. and 39in. CORR - A - FLEX tubing, multiple adaptor kit, and exhalation valve drivelines

Heat moisture exchanger features include: * 15/22 mm ID/OD x 22/15 mm ID/OD fittings * Dead Space 91.3 mL * CO2 Port * BFE > 99.99% * VFE > 99.99%

IPPB Mouthpiece has been designed with a maximum inside diameter to assist the free flow of air. * Constructed of translucent plastic * Molded for a comfortable fit * Designed for maximum airflow

Flex tube includes 15 mm x 15 mm fittings.

Heat moisture exchangers with various options.

Combination includes one HME and one flex tube.

Hepashield™ pleated hydrophobic bacterial/viral mechanical filters minimize flow resistance and maximize surface area for superior filtration efficiency. * Secure Luer Lock * Push-fit tethered luer lock cap, secured with a strap reducing the risk of misplacement or loss. * Universal Connection * The 22M/15F – 22F/15M connectors prevent fitting in the wrong direction, and comply with current ISO 5356-1:2015 standards, making them compatible for use with all breathing systems. * Reduced Drag * Light weight construction reduces drag on the breathing system and airway. * Rounded Edges * Smooth contours prevent pressure marks on the patient.
